簡介：
| ● |
Raw material complies with CNS-9278/JISG-3141/ISO-3574 |
| ● |
Designed, manufactured by CNS-13626 standard |
| ● |
Complies with IMO regulations and are UN approved. |
| ● |
Containing applications : Petrochemical related products Resolvent,Resin,Lubricant),Printing Ink,Oil,Juice,Honey,Screws,Powder etc. |
| ● |
Steel thicknesses range from 0.5mm to 0.8mm(can be customized). |
| ● |
Type of Hoops:Rolling Beads,W-Hoop. |
| ● |
Choice of Lever-Lock Ring or Bolt Ring. |
Specifications：
| |
Product |
Dimensions(mm) |
| T |
ID |
H |
| 1 |
20L Open-Head Steel Pail |
0.5~0.8 |
Ø326±3 |
285±5 |
| 0.5~0.8 |
Ø280±3 |
420±5 |
| 2 |
30(35)L Open-Head Steel Pail |
0.5~0.8 |
Ø330±3 |
440±5 |
| 3 |
50L Open-Head Steel Pail |
0.5~0.8 |
Ø380±3 |
450±5 |
| 4 |
55L Open-Head Steel Pail |
0.5~0.8 |
Ø380±3 |
560±5 |
| 5 |
60L Open-Head Steel Pail |
0.5~0.8 |
Ø380±3 |
600±5 |
| 6 |
70L Open-Head Steel Pail |
0.5~0.8 |
Ø380±3 |
645±5 |
| 7 |
85L Open-Head Steel Pail |
0.5~0.8 |
Ø435±3 |
600±5 |
| 8 |
100L Open-Head Steel Pail |
0.5~0.8 |
Ø435±3 |
820±5 |
| 9 |
120L Open-Head Steel Pail |
0.5~0.8 |
Ø435±3 |
830±5 |
Listed above are for the primary customer commonly usage. We can also customize the drum
according to customer’s requirement from 20L ~ 120L. |
